Combattante FS 46 Fast Attack Craft
(CMN - Constructions Mecaniques de Normandie)



The Combattante FS46, evolution of sea proven CMN Combattante II class, is a Fast Attack Craft, able to perform with a high level of efficiency the tasks required by a Patrol Missile Boat mission's profiles.
Description

The Combattante FS46, evolution of sea proven CMN Combattante II class, is a Fast Attack Craft, able to perform with a high level of efficiency the tasks required by a Patrol Missile Boat mission's profiles.


Contact

CMN
51 Rue de la Bretonnière - BP 539
50105 Cherbourg Cedex - FRANCE
Phone: +33 (0)2 33 88 30 00
Fax: +33 (0)2 33 88 30 00
This email address is being protected from spambots. You need JavaScript enabled to view it.

Variants
- Ocean Eagle trimaran patrol craft
Technical Data
Back to top
Design
» Combine speed and fire power with optimization of acquisition cost
» Compact and multifunction vessel, capable of high performances
» Stealth aspect
» Perfect 360° view all around the vessel
Missions
» Fast strike against surface and coastal targets
» Coastal and off-shore patrolling
» Interception of narcotics, smuggling and illegal immigration
» Interception of enemy forces
» Economic Exclusive Zone (EEZ) monitoring & surveillance
» Naval and law enforcement application
» Support to Land Forces actions operations
» Air self defence
Typical Mission Systems

» One Mission Management System with Data Link
» One Surveillance Radar
» One Primary Gun: 40MM
» One Electro-optical fire control system
» One Surface to Surface Missile System (4 missiles)
» One Short Range Air Defence Missile System or one secondary Gun (up to 40 mm)
» Two remote controlled side guns (up to 30 mm)
» One Decoy Launching System
» One Integrated Naval communication system
» GMDSS
» One Integrated Navigation System

Main Equipment & Auxiliaries
» Two main generating sets
» One emergency generating set
» Three high speed diesel engines
» Three Fixed Pitch Propellers (FPP)
» One 5.25m RHIB

Specifications
Type
FACM (Fast Attack Craft Missile)
Crew
24
Operators
-
Performance
Speed: >35 kts
Range: 2,000 nm @ 15 kts
Endurance: n/a
Fuel
63m3
Fresh water
6.4m3
Hull & Superstructure
Steel/Aluminium

Dimensions

Length: 46.0 m
Bream: 7.45 m
Maximum Draft: 4.2 m

Detailed View
The Combattante FS46, evolution of sea proven CMN Combattante II class, is a Fast Attack Craft, able to perform with a high level of efficiency the tasks required by a Patrol Missile Boat mission's profiles.
The Combattante FS46, evolution of sea proven CMN Combattante II class, is a Fast Attack Craft, able to perform with a high level of efficiency the tasks required by a Patrol Missile Boat mission's profiles.
